System One RW41 Reader/Writer Encoder


Category: SKU: ALS1-ENC-RW41-ACS


The RW41 reader/writer encoder is used to write the guest keys and staff keys. It is also used to encode certain other special-function keys for programming […]

$300.00

The RW41 reader/writer encoder is used to write the guest keys and staff keys. It is also used to encode certain other special-function keys for programming locks, interrogating locks, and resetting the date/time.

TECH SPECS: – Download .pdf

Physical Characteristics
Dimensions (mm) 120.5 mm (L) x 72.0 mm (W) x 20.4 mm (H)
Weight (g) 140 g
USB Interface
Protocol USB HID Keyboard Class
Connector Type Standard Type A
Power Source From USB port
Speed USB Full Speed (12 Mbps)
Cable Length 2.0 m, Fixed
Contactless Smart Card Interface
Standard ISO 14443 A & B Parts 1-4, MIFARE®
Protocol ISO 14443-4 Compliant Card, T=CL
MIFARE® Classic Card, T=CL
Built-in Peripherals
LED 2 single-color: Red and Green
Buzzer Monotone
Other Features
Firmware Upgrade Supported
Certifications/Compliance
Certifications/Compliance ISO 14443
USB Full Speed
USB-HID
CE
FCC
RoHS 2
Device Driver Operating System Support
Device Driver Operating System Support Windows®
Linux®
MAC OS®
Android™

Weight 2 lbs
Dimensions 8 × 8 × 8 in
